3628 DC12V COOLING FAN

9HV3612P3K001

Brand: SanAce (Japan sanyodenki)
Size: 36x36x28mm
Characteristics: High rotational speed, high static pressure, high air volume
Signal line: 4-wire PWM + FG
Product description: Sanyo Denki 9HV3612P3K001 DC Axial Fan, 36x36x28mm frame, 12V/1.75A. Features 1400Pa high static pressure, 25.4CFM airflow, PWM control and pulse sensor. Long life 30,000 hours. Ideal for demanding co
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
	9HV3612P3K001	12	10.8~13.2	1.75	21.0	32500	0.72	25.4	1400		5.62	67

PRODUCT PRESENTATION

San Ace 36 DC Cooling Fan 9HV3612P3K001 Product Details

Product Overview

The San Ace 36 DC Cooling Fan 9HV3612P3K001 is a high-performance axial cooling fan designed for efficient thermal management in various electronic and industrial applications. Manufactured by Sanyo Denki, this fan combines reliability with advanced features such as PWM control and a pulse sensor for precise speed monitoring. With a compact frame size of 36mm x 36mm x 28mm, it is ideal for space-constrained environments where effective cooling is essential.

Key Features

Compact Design: Small footprint suitable for tight spaces.
PWM Control: Allows for precise speed control and energy efficiency.
Pulse Sensor: Enables real-time monitoring of fan speed.
High Performance: Delivers maximum airflow of 0.72 m³/min and static pressure of 1400 Pa.
Durability: Designed for long life with an expected lifespan of 30,000 hours at 60°C.
Wide Operating Temperature Range: Functions effectively from -20°C to +60°C.
Compliance: Meets Eco Products, UL, CSA, EN standards, and RoHS directive.

Specifications

Parameter	Value
Model No.	9HV3612P3K001
Frame Size [mm]	36
Frame Thickness [mm]	28
Frame Material	Plastic
Rated Voltage [V]	12
Operating Voltage Range [V]	10.8 ~ 13.2
Rated Current [A]	1.75
Rated Input [W]	21.0
Rated Speed [min⁻¹]	32,500
Max. Airflow [m³/min]	0.72
Max. Airflow [CFM]	25.4
Max. Static Pressure [Pa]	1400
Max. Static Pressure [inchH₂O]	5.62
SPL [dB(A)]	67
Operating Temperature [°C]	-20 ~ +60
Expected Life [h]	30,000/60°C (53,000/40°C)
Mass [g]	53
Sensor Type	Pulse sensor
PWM Control Function	Yes
Ribs	Yes

Applications

Industry/Field	Specific Use Cases
Electronics	Cooling for PCBs, power supplies, and electronic enclosures.
Industrial Equipment	Thermal management in control panels, automation systems, and machinery.
Telecommunications	Cooling for network switches, routers, and communication base stations.
Consumer Electronics	Integration into gaming consoles, high-performance computers, and audio equipment.
Medical Devices	Ensuring optimal operating temperatures in diagnostic and therapeutic equipment.
Automotive	Cooling for in-vehicle electronics and infotainment systems.

Compliance and Standards

Standard	Description
Eco Products	Environmentally friendly design.
UL Ratings	Meets UL safety standards.
CSA Standards	Complies with Canadian Safety Association standards.
EN Standards	Meets European Norm standards.
RoHS Directive	Restriction of Hazardous Substances compliant.

Download Materials

For further technical details, please refer to the download materials list available on the product page.

Related Information

Additional information regarding applicable models and related products can be found in the related information section.
