4020 5V DC COOLING FAN

109P0405M601

Brand: SanAce (Japan sanyodenki)
Size: 40x40x20mm
Characteristics: Low power consumption, low noise, long lifespan
Signal line: 3-wire
Product description: SANYO DENKI San Ace 40 series 109P0405M601 DC cooling fan, 5V voltage, 5000 RPM speed, airflow 0.136 m³/min, noise 24 dB(A). Ideal for low-power devices, small industrial control systems, and embedded
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
	109P0405M601	5	4.5~5.5	0.12	0.6	5000	0.136	4.8	26.5	2.6924	0.106	24

PRODUCT PRESENTATION

1. Product Introduction

The 109P0405M601 is a high-efficiency axial DC cooling fan from SANYO DENKI’s San Ace 40series. Designed for compact spaces, it combines low power consumption, quiet operation, and reliable cooling performance. With dimensions of 40×40×20 mm, this fan is ideal for applications requiring efficient heat dissipation in tight enclosures.

2. Key Specifications (Table)

Parameter	Specification	Unit
Model No.	109P0405M601	-
Frame Size	40 × 40	mm
Frame Thickness	20	mm
Frame Material	Plastic	-
Rated Voltage	5	V
Operating Voltage Range	4.5 ~ 5.5	V
Rated Current	0.12	A
Rated Input	0.6	W
Rated Speed	5000	min⁻¹
Max. Airflow	0.136 (CFM: 4.8)	m³/min
Max. Static Pressure	26.5 (inchH₂O: 0.106)	Pa
Sound Pressure Level (SPL)	24	dB(A)
Operating Temperature	-20 ~ +70	°C
Expected Life	60000 h (60°C) / 90000 h (40°C)	h
Mass	45	g
Sensor Type	Pulse sensor	-
PWM Control Function	No	-
Ribbed	Yes	-

3. Performance Highlights

Efficient Cooling:livers a maximum airfl Deow of 0.136 m³/min (4.8 CFM) and static pressure of 26.5 Pa (0.106 inchH₂O), ensuring effective heat removal from compacts.
space Low Power & Noise: Operates at 5V with a rated current of 0.12A (0.6W input), while maintaining a quiet SPL of 24 dB(A) — ideal for noise-sensitive environments.
Reliable Operation: Features a pulse sensor for speed monitoring and a ribbed frame design for enhanced structural stability. Rated for 60,000 hours at 60°C (90,000 hours at 40°C).

4. Application Scenarios

Low-Power Electronics: Cooling for embedded systems, IoT devices, and battery-powered equipment.
Industrial Control: Ventilation in small PLCs, industrial computers, and control cabinets.
Consumer Electronics: Heat dissipation in compact printers, projectors, and home automation hubs.
Medical Devices: Quiet cooling for portable medical equipment (e.g., diagnostic tools, infusion pumps).

5. Design & Build

Compact Form Factor: 40×40×20 mm size fits seamlessly into space-constrained designs.
Durable Construction: Plastic frame with ribbed design ensures strength and longevity, even in continuous operation.
Wide Voltage Range: Operates reliably between 4.5V–5.5V, making it compatible with most 5V power systems.

6. Why Choose 109P0405M601?

Balanced Performance: Combines low power, quiet operation, and sufficient airflow for small-scale cooling needs.
Trusted Brand: Backed by SANYO DENKI’s reputation for high-quality cooling solutions.
Long Lifespan: Extended operational life reduces maintenance and replacement costs.

This fan is a versatile solution for applications where space, noise, and energy efficiency are critical. For detailed datasheets or customization, visit SANYO DENKI’s official support portal.
