Sanyo Denki San Ace 40 9GAX0412P3K0031 DC Cooling Fan Full Product Introduction

1. Product Overview

2. Complete Technical Specification Table

Table 1 Full Electrical & Mechanical Specifications

Table 2 Certification Standard List

3. Core Performance Parameter Explanation Table

Table 3 Key Performance Advantage Breakdown

4. Functional Module Detailed Introduction

4.1 PWM Speed Control Function

• Reduce fan speed under low load temperature to cut power consumption and running noise;
• Automatically boost to full speed when equipment temperature rises to ensure heat dissipation capacity;
• Perfect match with intelligent temperature control mainboards of servers and industrial control equipment.

4.2 Pulse Tachometer Speed Sensor

• Real-time monitoring of fan working status;
• Automatic alarm trigger when fan stall, abnormal speed or failure occurs;
• Avoid equipment overheating damage caused by fan shutdown, greatly improve equipment operation safety.

Table 4 Function Module Contrast with Ordinary 4028 Fans

5. Operating Environment & Service Life Specification

Table 5 Environment Adaptation & Lifespan Data

6. Main Application Scenarios

Table 6 Recommended Matching Equipment Fields

7. Product Material & Structure Description

1. Frame: High-strength flame-retardant engineering plastic, impact-resistant, anti-aging, no ribbed design, smooth air inlet and outlet to reduce wind resistance loss.
2. Motor Core: Sanyo Denki self-developed DC brushless motor, low power consumption, small electromagnetic interference, stable torque output at ultra-high speed.
3. Wiring Interface: Standard built-in wire harness supporting PWM control and pulse signal dual signal transmission, convenient for customer wiring integration.
4. Overall Size Standard: Strict 40mm square frame, 28mm thickness, unified industry standard mounting hole position, easy replacement of old cooling fans.

8. Global Certification Advantage Summary

1. UL Ratings: Authorized safety certification for the North American market;
2. CSA Standards: Canadian electrical safety certification, supporting Canada cross-border sales;
3. EN Standards: EU industrial electrical safety standard, compliant for European market listing;
4. RoHS Directive: Restriction of Hazardous Substances certification, green and environmentally friendly, meets global electronic product environmental protection requirements.

9. Purchase & Matching Suggestion

• Matching voltage: Must use 10.8~13.2V DC power supply, rated optimal operating voltage 12V;
• Control matching: The host mainboard needs to reserve PWM control port and pulse signal detection port to realize full fan function;
• Installation suggestion: Install vertically or horizontally, avoid long-term operation in high-dust, high-humidity corrosive environment, add dust-proof net if necessary;
• Alternative models: If lower rotation speed or different airflow pressure is required, consult Sanyo Denki San Ace 40 series other model variants for parameter comparison.
