Product Overview
The SANYO DENKI San Ace 9GA0412P6H001 is a high-performance, low power consumption 40x40x20mm DC axial cooling fan designed for efficient thermal management in compact spaces. Operating at 12V with a rated current of 0.14A, this fan combines energy efficiency with reliable performance, making it ideal for applications where space and power constraints are critical.
Featuring PWM (Pulse Width Modulation) speed control, the 9GA0412P6H001 allows precise adjustment of fan speed to match cooling demands, reducing noise and power consumption during low-load conditions. With a maximum airflow of 0.33m³/min (11.7CFM) and a static pressure of 191Pa (0.77inchH2O), it effectively dissipates heat from high-density electronic components.
Built with a durable plastic frame and ribbed design, the fan operates within a wide temperature range (-20°C to +70°C) and offers an expected life of 60,000 hours at 60°C (90,000 hours at 40°C), ensuring long-term reliability in demanding environments.
Key Features
-
Low Power Consumption: Rated at 1.68W (12V, 0.14A), minimizing energy usage.
-
PWM Control: Enables dynamic speed adjustment for optimized cooling and noise reduction.
-
High Efficiency: Delivers 0.33m³/min airflow and 191Pa static pressure for effective heat dissipation.
-
Compact Design: 40x40x20mm form factor fits into tight spaces.
-
Long Lifespan: 60,000 hours (L10) at 60°C, 90,000 hours at 40°C.
-
Wide Operating Temperature: -20°C to +70°C, suitable for harsh environments.
-
Low Noise: 40dB(A) sound pressure level for quiet operation.
Technical Specifications
|
Parameter
|
Specification
|
|
Model No.
|
9GA0412P6H001
|
|
Frame Size
|
40mm
|
|
Frame Thickness
|
20mm
|
|
Rated Voltage
|
12V DC
|
|
Operating Voltage Range
|
10.2V ~ 13.8V
|
|
Rated Current
|
0.14A
|
|
Rated Input
|
1.68W
|
|
Rated Speed
|
12,400 min⁻¹
|
|
Max. Airflow
|
0.33m³/min (11.7CFM)
|
|
Max. Static Pressure
|
191Pa (0.77inchH2O)
|
|
Sound Pressure Level (SPL)
|
40dB(A)
|
|
Operating Temperature
|
-20°C ~ +70°C
|
|
Expected Life
|
60,000h (60°C), 90,000h (40°C)
|
|
Mass
|
35g
|
|
Sensor Type
|
Pulse sensor
|
|
PWM Control Function
|
Yes
|
|
Frame Material
|
Plastic (Ribbed)
|
Applications
The San Ace 9GA0412P6H001 is ideal for cooling in:
-
Industrial Equipment: PLCs, motor drives, and control panels.
-
Electronics: Power supplies, LED lighting, and communication devices.
-
Medical Devices: Diagnostic equipment and laboratory instruments.
-
Consumer Electronics: Gaming consoles, set-top boxes, and home appliances.
-
Automotive: In-vehicle infotainment systems and battery management.
Why Choose San Ace 9GA0412P6H001?
SANYO DENKI’s San Ace series is renowned for its reliability and innovation in thermal management. The 9GA0412P6H001 combines low power consumption with high performance, making it a cost-effective solution for applications requiring efficient cooling in compact spaces. Its PWM control capability ensures adaptability to varying thermal loads, while the robust design guarantees long-term operation in challenging environments.
∷
