4020 24V Low Power Consumption Fan

9GA0424P6H001

Brand: SanAce (Japan sanyodenki)
Size: 40x40x20mm
Characteristics: Low power consumption, low noise, long lifespan
Signal line: 4-wire PWM + FG
Product description: SANYO DENKI San Ace 40 series DC cooling fan 9GA0424P6H001, size 40x40x20mm, rated voltage 24V. Features PWM control, low power consumption (1.92W), and high speed (12400 rpm). Max airflow is 0.33m³/m
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
	9GA0424P6H001	24	20.4~27.6	0.08	1.92	12400	0.33	11.7	191	19.558	0.77	40

PRODUCT PRESENTATION

Product Overview

San Ace 40 Low Power Consumption Fan – Model 9GA0424P6H001

The San Ace 40 (9GA0424P6H001) is a high-performance, low power consumption DC axial flow fan designed by SANYO DENKI. With a compact frame size of 40mm and a thickness of 20mm, this fan delivers exceptional cooling efficiency for space-constrained applications.

Featuring PWM control functionality, this fan allows for precise speed control based on temperature requirements, ensuring optimal thermal management and energy efficiency. It operates at a rated voltage of 24V and is constructed with durable plastic materials, making it suitable for a wide range of industrial and electronic cooling applications.

Key Features

Compact & Lightweight: 40mm frame size with only 20mm thickness and 35g mass.
PWM Control: Enables precise speed control via Pulse Width Modulation (4-wire type).
Low Power Consumption: Rated input of only 1.92W, contributing to energy-saving system designs.
High Reliability: Expected life of 60,000 hours at 60°C (and 90,000 hours at 40°C).
Wide Operating Temperature: Reliable operation from -20°C to +70°C.
Ribbed Frame: Reinforced frame structure for increased rigidity and reduced vibration.

Technical Specifications

The following table details the performance metrics for the 9GA0424P6H001 model:

表格

Parameter	Specification
Model No.	9GA0424P6H001
Frame Size	40 mm
Frame Thickness	20 mm
Rated Voltage	24 VDC
Operating Voltage Range	20.4 ~ 27.6 VDC
Rated Current	0.08 A
Rated Input Power	1.92 W
Rated Speed	12,400 min⁻¹ (RPM)
Max. Airflow	0.33 m³/min (11.7 CFM)
Max. Static Pressure	191 Pa (0.77 inchH2O)
Sound Pressure Level (SPL)	40 dB(A)
Sensor Type	Pulse Sensor (2 pulses per revolution)
PWM Control	Yes
Frame Material	Plastic (Ribbed)
Mass	35 g
Operating Temperature	-20 ~ +70 °C
Expected Life	60,000 hours @ 60°C / 90,000 hours @ 40°C

Applications

The San Ace 40 9GA0424P6H001 is ideal for cooling high-density electronic components where space is limited but airflow is critical. Typical applications include:

Telecommunication Equipment: Cooling for base stations and network routers.
Industrial Control Systems: PLCs, inverters, and servo drives.
Office & Consumer Electronics: High-performance projectors, 3D printers, and laser processing machines.
Medical Equipment: Diagnostic devices and analysis instruments requiring reliable, quiet cooling.
Automotive & EV: Battery management systems (BMS) and onboard chargers.

Performance Characteristics

Airflow vs. Static Pressure: This model is optimized to provide a balance between high airflow (0.33 m³/min) and significant static pressure (191 Pa), allowing it to push air through restricted spaces and heatsinks effectively.
Noise Performance: Despite its high speed (12,400 RPM), the fan is engineered to maintain a sound pressure level of 40 dB(A), ensuring it meets noise regulations for various environments.

Compliance & Standards

Eco Products: Designed with environmental considerations.
Safety Standards: UL / CSA / EN standards compliant.
Environmental: RoHS Directive compliant.
