4028 24V Low Power Consumption Fan

9GA0424P3G0011

Brand: SanAce (Japan sanyodenki)
Size:40x40x28mm
Characteristics: Low power consumption, low noise, long lifespan
Signal line: 4-wire PWM + FG
Product description: San Ace 9GA0424P3G0011 is a 40×40×28mm low power consumption DC cooling fan developed by SANYO DENKI. Featuring a rated voltage of 24V, speed of 16,500 min⁻¹, maximum airflow of 0.61 m³/min and static
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
暂无	9GA0412P3J01	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3J011	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3G01	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3G011	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3H01	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3H011	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3M01	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0412P3M011	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3J001	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3J0011	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3G001	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
	9GA0424P3G0011	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3H001	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3H0011	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3M001	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3M0011	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0412A301	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43
暂无	9GA0412A3011	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43

PRODUCT PRESENTATION

San Ace 9GA0424P3G0011 40×40×28mm Low Power Consumption DC Cooling Fan

The San Ace 9GA0424P3G0011 is a compact and reliable DC cooling fan developed by SANYO DENKI.

Designed for applications requiring efficient cooling in limited installation spaces, this model combines low power consumption, high-speed operation, PWM control capability and pulse sensor monitoring.

With a compact 40×40×28mm frame size, the fan delivers a maximum airflow of 0.61 m³/min (21.5 CFM) and maximum static pressure of 450 Pa (1.81 inchH₂O), making it suitable for cooling systems with airflow resistance.

The fan supports PWM speed control, allowing intelligent adjustment of cooling performance according to system requirements.

Product Overview

Item	Specification
Manufacturer	SANYO DENKI
Product Series	San Ace
Model Number	9GA0424P3G0011
Product Name	Low Power Consumption Fan
Fan Type	DC Cooling Fan
Fan Size	40×40mm
Fan Thickness	28mm
Rated Voltage	24V DC
Control Function	PWM Control
Sensor Function	Pulse Sensor
Frame Design	Standard Frame

Technical Specifications

Parameter	Specification
Model	9GA0424P3G0011
Rated Voltage	24V
Rated Current	0.22A
Rated Power Consumption	5.28W
Rated Speed	16,500 min⁻¹
Maximum Airflow	0.61 m³/min
Maximum Airflow	21.5 CFM
Maximum Static Pressure	450 Pa
Maximum Static Pressure	1.81 inchH₂O
Noise Level	53 dBA
Expected Life	40,000 hours at 60℃
Expected Life	70,000 hours at 40℃
Sensor Type	Pulse Sensor
PWM Control	Yes
Ribbed Frame	No

Compact Size for Space-Limited Cooling Applications

Modern electronic equipment requires higher performance while maintaining smaller dimensions.

The San Ace 9GA0424P3G0011 provides an efficient cooling solution through:

Compact 40mm frame design
High-speed motor technology
Optimized airflow structure
Low power consumption operation

Although the fan size is compact, it achieves a maximum static pressure of:

450 Pa

This allows effective cooling in applications where airflow resistance exists, including:

Heat sinks
Dense electronic assemblies
Narrow ventilation paths
Compact enclosures

Low Power Consumption Design

Energy efficiency is an important requirement for modern industrial equipment.

The San Ace 9GA0424P3G0011 consumes only:

5.28W rated power

while maintaining high cooling performance.

Advantages include:

Feature	Benefit
Low power consumption	Reduced system energy usage
Efficient motor design	Improved operating efficiency
Stable airflow output	Reliable thermal performance
Compact structure	Flexible installation

PWM Control Function

The built-in PWM control function enables dynamic speed adjustment.

The system controller can adjust fan speed according to:

Temperature changes
Equipment workload
Cooling requirements

Benefits:

Traditional Fan	PWM Controlled Fan
Fixed speed operation	Adjustable speed
Higher energy consumption	Energy optimized
Continuous maximum cooling	Demand-based cooling
Less intelligent control	Smart thermal management

Pulse Sensor Monitoring

The integrated pulse sensor provides fan rotation feedback.

This function helps equipment manufacturers achieve:

Function	Advantage
Fan status monitoring	Detect operating conditions
Failure detection	Prevent overheating risks
System protection	Improve reliability
Maintenance planning	Reduce downtime

Application Areas

Application	Cooling Requirements
Industrial Controllers	Stable continuous cooling
Communication Equipment	Compact thermal management
Power Supply Equipment	Reliable airflow
Automation Systems	Long-life operation
Medical Equipment	Stable cooling performance
Embedded Devices	Space-saving design

Product Advantages

Advantage	Description
Compact 40×40×28mm size	Suitable for limited installation space
High speed 16,500 min⁻¹	Provides strong cooling capability
450Pa static pressure	Handles airflow resistance
PWM control	Enables intelligent cooling
Pulse sensor	Supports monitoring function
Long life design	Reduces maintenance requirements

Recommended Applications

The San Ace 9GA0424P3G0011 is ideal for equipment requiring:

Compact cooling solutions
24V DC power supply
High reliability operation
Intelligent fan control
Long service life
Efficient thermal management

Conclusion

The SANYO DENKI San Ace 9GA0424P3G0011 is a compact, efficient and reliable 40mm DC cooling fan designed for industrial applications.

With low power consumption, PWM speed control, pulse sensor feedback and high static pressure capability, this fan provides an excellent thermal solution for compact electronic systems, industrial equipment and power-related applications.
