4028 24V Low Power Consumption Fan

9GA0424P3H0011

Brand: SanAce (Japan sanyodenki)
Size:40x40x28mm
Characteristics: Low power consumption, low noise, long lifespan
Signal line: 4-wire PWM + FG
Product description: Sanyo Denki San Ace 40 model 9GA0424P3H0011 is a 40×40×28mm low power consumption DC cooling fan with standard flat plastic frame without ribbed structure. This 24V fan runs at 14500RPM, delivers 0.54
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
暂无	9GA0412P3J01	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3J011	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3G01	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3G011	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3H01	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3H011	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3M01	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0412P3M011	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3J001	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3J0011	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3G001	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3G0011	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3H001	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
	9GA0424P3H0011	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3M001	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3M0011	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0412A301	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43
暂无	9GA0412A3011	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43

PRODUCT PRESENTATION

San Ace 40 Low Power Consumption Fan Model 9GA0424P3H0011

Product Overview

9GA0424P3H0011 belongs to Sanyo Denki San Ace 40 compact DC axial fan series, outer dimension 40mm × 40mm × 28mm. This model adopts flat non ribbed plastic frame design which is the core difference compared with ribbed version 9GA0424P3H001. It maintains low power consumption performance while keeping high airflow and high static pressure output. Built with PWM speed adjustment circuit and pulse speed sensor, it realizes intelligent speed regulation and real time operating status monitoring.

This cooling fan passes UL, CSA, EN and RoHS global certification, low power consumption design meets eco product standard, suitable for small space heat dissipation scenarios that require smooth frame without extra rib protrusion.

Full Technical Parameter Table

表格

Parameter Item	Technical Value	Parameter Item	Technical Value
Model Number	9GA0424P3H0011	Frame Overall Size	40mm
Frame Thickness	28mm	Frame Material	Plastic Non Ribbed Frame
Rated Voltage	24V DC	Working Voltage Range	21.6V ~ 26.4V DC
Rated Current	0.16A	Rated Input Power	3.84W
Rated Rotation Speed	14500 min⁻¹	Maximum Airflow	0.54 m³/min
Max Airflow CFM	19.1 CFM	Maximum Static Pressure	347 Pa
Max Static Pressure inchH2O	1.39 inchH2O	Sound Pressure Level	50 dB(A)
Operating Temperature	-20℃ ~ +70℃	Expected Service Life	40000h at 60℃, 70000h at 40℃
Net Weight	53g	Speed Feedback Sensor	Pulse sensor
PWM Speed Control	Supported	Ribbed Frame Structure	No

Core Performance Comparison Table

表格

Performance Index	Data Value	Practical Application Advantage
High Rotation Speed 14500RPM	14500 revolutions per minute	Fast heat exhaust for sealed small equipment with concentrated heat source
High Static Pressure 347Pa	347 Pa wind pressure	Stable air output when working with dense heat sinks or dust filters
Low Power Rated 3.84W	Low power motor core	Reduce long term energy consumption of terminal equipment batches
Wide Voltage Adaptation	21.6V to 26.4V DC	Stable operation under industrial power supply voltage fluctuation
50dB(A) Noise Level	Balanced low noise	Avoid noise interference for indoor industrial and office equipment

Built-in Function Configuration Table

表格

Function Module	Function Working Principle	Customer Application Value
PWM Speed Control Function	Adjust fan rotating speed through external PWM signal input	Realize temperature linked intelligent cooling, lower power loss and running noise at low load
Pulse Speed Sensor	Output pulse signal corresponding to real time fan speed	Main control system can judge fan stall, abnormal rotation speed and send fault alarm signal
Flat Non Ribbed Frame	Smooth plastic frame without protruding reinforcing ribs	Adapt ultra narrow installation gaps, easy assembly in limited internal equipment space, no rib collision risk during installation

Global Compliance Certification Table

表格

Certification Item	Compliance Result	Market Access Benefit
UL Safety Rating	Fully Compliant	Meet North American industrial equipment export safety standard
CSA Standard Certification	Fully Compliant	Support product sales and certification in Canada market
EN European Safety Standard	Fully Compliant	Comply with EU electrical product access regulations
RoHS Environmental Directive	Fully Compliant	Lead free low hazardous material composition, meet global environmental export requirements
Eco Product Standard	Qualified Low Power Product	Reduce carbon emission of terminal devices, match green manufacturing demand

Service Life and Operating Environment Description

9GA0424P3H0011 fan uses high wear resistant bearing system, continuous working service life changes with ambient temperature:

40000 hours continuous running under 60℃ ambient temperature
70000 hours continuous running under 40℃ ambient temperature

The allowable working temperature range covers minus 20 degrees Celsius to plus 70 degrees Celsius, compatible with low temperature cold storage equipment and high temperature closed control cabinet working environment without performance attenuation.

Main Application Scenarios

1U and 2U rack mounted server internal heat dissipation
Compact industrial PLC, servo driver and small control cabinet cooling
Mini network switches, communication power supply equipment
Portable precision medical testing instruments
Small automated industrial equipment with narrow installation clearance

Structural Feature Introduction

Standard 4028 square frame size, universal mounting hole position, convenient replacement of old cooling fans
Smooth non rib plastic shell design, no protruding ribs, suitable for equipment with limited internal installation gap
Light weight total mass only 53g, will not bring extra load to miniature precision equipment
Integrate PWM speed regulation and pulse speed detection dual functions, single fan realizes intelligent heat dissipation monitoring without additional accessory installation
Low power consumption motor design, reduce long term operation cost for mass equipment deployment
