4028 24V Low Power Consumption Fan

9GA0424P3G001

Brand: SanAce (Japan sanyodenki)
Size:40x40x28mm
Characteristics: High rotational speed, high static pressure, high air volume
Signal line: 4-wire PWM + FG
Product description: San Ace 9GA0424P3G001 is a 40×40×28mm low power consumption DC cooling fan developed by SANYO DENKI. Operating at 24V with a rated speed of 16,500 min⁻¹, this compact fan provides maximum static press
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
暂无	9GA0412P3J01	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3J011	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3G01	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3G011	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3H01	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3H011	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3M01	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0412P3M011	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3J001	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3J0011	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
	9GA0424P3G001	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3G0011	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3H001	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3H0011	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3M001	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3M0011	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0412A301	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43
暂无	9GA0412A3011	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43

PRODUCT PRESENTATION

San Ace 9GA0424P3G001 40×40×28mm Low Power Consumption DC Cooling Fan

The San Ace 9GA0424P3G001 is a compact and high-performance DC cooling fan developed by SANYO DENKI.

Designed for applications requiring efficient cooling in limited spaces, this model combines low power consumption, high static pressure performance and intelligent control functions.

With a compact 40×40×28mm frame size, the fan delivers a maximum airflow of 0.61 m³/min and maximum static pressure of 450 Pa, making it suitable for electronic equipment where airflow resistance is a concern.

The built-in PWM control function enables variable speed adjustment according to system requirements, while the pulse sensor function provides real-time fan operation monitoring.

Product Overview

Item	Specification
Product Series	San Ace
Manufacturer	SANYO DENKI
Model Number	9GA0424P3G001
Product Name	Low Power Consumption Fan
Fan Type	DC Cooling Fan
Frame Size	40mm
Fan Dimensions	40×40×28mm
Rated Voltage	24V DC
PWM Control	Available
Sensor Function	Pulse Sensor
Frame Structure	Ribbed Frame

Technical Specifications

Parameter	Specification
Model	9GA0424P3G001
Rated Voltage	24V
Rated Current	0.22A
Rated Power Consumption	5.28W
Rated Speed	16,500 min⁻¹
Maximum Airflow	0.61 m³/min
Maximum Airflow	21.5 CFM
Maximum Static Pressure	450 Pa
Maximum Static Pressure	1.81 inchH₂O
Noise Level	53 dBA
Expected Life	40,000 hours at 60℃
Expected Life	70,000 hours at 40℃
Sensor Type	Pulse Sensor
PWM Control Function	Yes
Ribbed Frame	Yes

Compact 40mm Fan with High Cooling Performance

As electronic devices become smaller and more powerful, thermal management becomes increasingly challenging.

The San Ace 9GA0424P3G001 provides an optimized cooling solution by combining:

Compact installation size
High-speed rotation
Strong static pressure capability
Low power consumption design

Although the fan uses a compact 40mm frame, it achieves a maximum static pressure of:

450 Pa

This allows efficient cooling in systems with:

Narrow ventilation channels
Heat sinks
Air filters
High-density electronic components

Low Power Consumption Design

The 9GA0424P3G001 is designed to achieve effective cooling while reducing energy consumption.

Compared with conventional high-power cooling fans, this model provides:

Advantage	Benefit
Lower power consumption	Reduced system energy usage
Efficient motor design	Improved operating efficiency
Optimized airflow structure	Better cooling performance
Stable operation	Increased equipment reliability

The rated power consumption is only:

5.28W

making it suitable for energy-efficient industrial equipment.

PWM Speed Control Function

The built-in PWM control allows the fan speed to be adjusted according to thermal requirements.

Advantages of PWM Control

Conventional Fan	PWM Controlled Fan
Fixed operating speed	Variable speed operation
Continuous maximum cooling	Cooling based on actual demand
Higher energy consumption	Improved efficiency
Constant noise	Reduced noise under low load

PWM control helps achieve a balance between:

Cooling performance
Power consumption
Operating noise

Pulse Sensor Monitoring Function

The integrated pulse sensor provides feedback on fan rotation speed.

This enables equipment designers to:

Function	Benefit
Rotation monitoring	Real-time fan status detection
Failure warning	Prevent overheating risks
System protection	Improve equipment reliability
Maintenance planning	Support predictive maintenance

Ribbed Frame Structure

The San Ace 9GA0424P3G001 adopts a Ribbed Frame design.

Benefits include:

Feature	Advantage
Reinforced structure	Improved durability
Optimized airflow path	Enhanced pressure performance
Reduced vibration	Stable operation
Long-term reliability	Suitable for industrial environments

Applications

Application Field	Cooling Requirements
Industrial Controllers	Reliable continuous cooling
Communication Equipment	Compact thermal management
Power Supply Equipment	High pressure airflow
Automation Systems	Long service life
Medical Equipment	Stable operation
Embedded Devices	Space-saving cooling

Why Choose San Ace 9GA0424P3G001?

Feature	Benefit
40×40×28mm compact size	Easy installation in limited space
16,500 min⁻¹ speed	Strong cooling capability
450Pa static pressure	Suitable for airflow resistance
PWM control	Intelligent cooling adjustment
Pulse sensor	Reliable monitoring
Long expected life	Reduced maintenance frequency

Conclusion

The SANYO DENKI San Ace 9GA0424P3G001 is a compact, energy-efficient and reliable DC cooling fan designed for industrial applications.

With its combination of low power consumption, high static pressure performance, PWM speed control and pulse sensor monitoring, this 40mm cooling fan provides an effective thermal solution for compact electronic equipment, industrial systems and power-related applications.
