4028 24V Low Power Consumption Fan

9GA0424P3M001

品牌：日本山洋SanAce
尺寸：40*40*28mm
特性：低功耗低噪音
型号：9GA0424P3H0011
Product description: Sanyo Denki San Ace 40 model 9GA0424P3M001 is a 40x40x28mm ribbed frame DC cooling fan with ultra low power consumption design. Rated at 24V 0.11A only 2.64W, 12500 RPM rotation speed, max airflow 0.4
INQUIRY
Product Manual / Specification Sheet Download

PRODUCT SPECIFICATION

Document	MODEL	Rated Voltage	Operating Voltage Range	Rated Current	Rated Input Power	Speed	Maximum Air Flow		Maximun Air Pressure			Noise
承认书/规格书	型号	额定定压	电压范围	额定电流	额定功率	转速	最大风量		最大风压			噪音
PDF	PART NO.	VDC	VDC	Amp	Watt	R.P.M	㎥/min	CFM	Pa	mmH2O	INH2O	DB-A
暂无	9GA0412P3J01	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3J011	12	10.2~13.8	0.49	5.88	18000	0.67	23.7	535		2.15	54
暂无	9GA0412P3G01	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3G011	12	10.2~13.8	0.39	4.68	16500	0.61	21.5	450		1.81	53
暂无	9GA0412P3H01	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3H011	12	10.2~13.8	0.28	3.36	14500	0.54	19.1	347		1.39	50
暂无	9GA0412P3M01	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0412P3M011	12	10.2~13.8	0.21	2.52	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3J001	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3J0011	24	21.6~26.4	0.27	6.48	18000	0.67	23.7	535		2.15	54
暂无	9GA0424P3G001	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3G0011	24	21.6~26.4	0.22	5.28	16500	0.61	21.5	450		1.81	53
暂无	9GA0424P3H001	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
暂无	9GA0424P3H0011	24	21.6~26.4	0.16	3.84	14500	0.54	19.1	347		1.39	50
	9GA0424P3M001	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0424P3M0011	24	21.6~26.4	0.11	2.64	12500	0.46	16.2	258		1.04	47
暂无	9GA0412A301	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43
暂无	9GA0412A3011	12	10.2~13.8	0.13	1.56	10500	0.38	13.4	182		0.73	43

PRODUCT PRESENTATION

San Ace 40 Low Power Consumption Fan Model 9GA0424P3M001

Product Overview

The 9GA0424P3M001 is a member of Sanyo Denki San Ace 40 compact DC axial fan series, standard dimension 40mm × 40mm × 28mm with reinforced ribbed plastic frame. The core feature of this model is ultra low power consumption, with rated power only 2.64W and rated current 0.11A, lower power loss compared with other 4028 San Ace fan variants.

This fan integrates PWM speed control and pulse signal speed feedback sensor, supporting real time speed monitoring and stepless speed adjustment. It fully complies with global industrial safety and environmental standards including UL ratings, CSA standards, EN standards and RoHS directive, marked as eco friendly low power product, suitable for energy saving oriented small device heat dissipation projects.

Full Technical Specification Table

表格

Parameter Item	Technical Data	Parameter Item	Technical Data
Model Number	9GA0424P3M001	Frame size	40mm
Frame thickness	28mm	Frame material	Plastic ribbed frame
Rated voltage	24V DC	Operating voltage range	21.6V ~ 26.4V DC
Rated current	0.11A	Rated input power	2.64W
Rated speed	12500 min⁻¹	Max airflow	0.46 m³/min
Max airflow CFM	16.2 CFM	Max static pressure	258 Pa
Max static pressure inchH2O	1.04 inchH2O	SPL sound level	47 dB(A)
Operating temperature	-20℃ ~ +70℃	Expected service life	40000h at 60℃, 70000h at 40℃
Net mass	53g	Sensor type	Pulse speed sensor
PWM control function	Supported	Ribbed frame structure	Yes

Core Energy Saving Performance Table

表格

Performance Index	Actual Parameter	Energy Saving Application Advantage
Ultra low rated current	0.11A	Reduce overall circuit load of terminal equipment, lower power supply matching cost
Minimal rated power	2.64W	Cut long term electricity consumption for mass deployed equipment, lower operation cost
Moderate 12500 RPM speed	Stable medium high rotation speed	Balanced airflow output with less power waste compared to 14500RPM high power models
Low noise 47 dB(A)	Optimized blade design	Lower running noise for office and indoor industrial equipment
Wide voltage tolerance	21.6V to 26.4V DC	Maintain low power consumption under unstable industrial power supply voltage

Built-in Functional Configuration Table

表格

Function Module	Working Principle	Practical Value For Users
PWM speed control	Adjust fan speed via external PWM signal input	Achieve temperature linked intelligent cooling, further reduce power consumption and noise during light load operation
Pulse speed sensor	Output pulse signal proportional to real time fan rotation speed	Main control board can monitor fan running status, trigger fault alarm when stall or abnormal speed occurs
Ribbed reinforced frame	Integrated reinforcing ribs on plastic housing	Improve frame anti deformation performance, reduce high speed vibration, extend fan service life

Global Compliance Certification Table

表格

Certification Standard	Compliance Status	Market Access Value
UL Ratings	Passed	Meet safety requirements for North American industrial equipment export
CSA Standards	Passed	Support product certification and sales in Canada market
EN Standards	Passed	Comply with European electrical product safety regulations
RoHS Directive	Passed	Lead free low hazardous material composition, satisfy global green export standards
Eco Product Qualification	Approved Low Power Fan	Reduce carbon emission of finished equipment, match green manufacturing standards

Service Life and Operating Environment

The 9GA0424P3M001 adopts high wear resistant bearing system, continuous service life changes with ambient working temperature:

40000 hours continuous stable operation under 60℃ ambient temperature
70000 hours continuous stable operation under 40℃ ambient temperature

The operating temperature range covers minus 20 degrees Celsius to plus 70 degrees Celsius, which can adapt to low temperature storage equipment and high temperature closed control cabinet working conditions without performance degradation.

Typical Application Scenarios

Energy saving type 1U 2U rack server internal heat dissipation
Low power industrial PLC, miniature servo driver control cabinet cooling
Small network switches and low power communication power supply equipment
Portable precision medical testing instruments with low power consumption requirement
Compact automation equipment requiring long term low energy operation

Structural Feature Introduction

Standard 40×40×28mm square frame, universal mounting hole layout, easy replacement of old cooling fans
Reinforced ribbed plastic shell structure, enhance structural stability during long time high speed operation
Lightweight design with total mass only 53g, will not add extra load to miniature precision equipment
Dual function circuit integrated PWM control and pulse speed detection, no extra accessories needed for intelligent heat dissipation monitoring
Optimized low power motor core design, the best choice for mass equipment deployment focusing on energy consumption control
